postgres-schema-mcp

An MCP server that gives an AI agent read-only access to a PostgreSQL database. Browse the schema, follow foreign keys, search columns across hundreds of tables, run capped SELECTs, and export an offline data dictionary.

Writes are rejected, and there are tests that prove it.

It runs over stdio for one developer and over authenticated HTTP for a team.

npx postgres-schema-mcp

Three calls to answer a question no single tool answers: find the join column, follow the keys, then write the query. No schema pasted into the prompt and no column names guessed. The last few seconds are the part that matters more than the answer.

Nothing in that recording is staged. It is scripts/demo.mjs, a real MCP client driving the real server against the sample database below, and scripts/record-demo.ps1 re-records it. Both are committed so the GIF cannot quietly start showing something that is no longer true.

Why this one

Most database MCP servers hand an agent a connection and hope. This one assumes the agent will eventually be asked to do something destructive, by a confused user or a poisoned document, and is built so that the attempt fails three separate times.

The three layers are independent, and each is enough on its own:

1. The query is parsed and refused unless it is a single SELECT or WITH. Stacked statements, DDL, DML, SELECT INTO, data-modifying CTEs, DO blocks and functions that execute SQL passed as text are all refused. Thirty hostile statements are asserted rejected in test/injection.test.ts.
2. Every query runs inside BEGIN READ ONLY with a statement timeout and an idle-in-transaction timeout, and the transaction is always rolled back, never committed.
3. The role you connect as holds SELECT and nothing else. The GRANT statements are below.

The test suite proves layers 2 and 3 separately rather than together. One test connects as a superuser and confirms a write is still refused, which can only be the read-only transaction doing it. Another connects as the least-privileged role and confirms a sequence advance is refused there too, which the keyword parser never sees.

There is no READ_ONLY=false escape hatch. Setting READ_ONLY, PGSM_READ_ONLY, ALLOW_WRITES or PGSM_ALLOW_WRITES to anything at all makes the server refuse to start, with a message saying the switch does not exist. If you need writes, use a different server.

Install

Claude Code

claude mcp add postgres-schema \
  --env DATABASE_URL=postgres://mcp_reader:PASSWORD@localhost:5432/yourdb \
  -- npx -y postgres-schema-mcp

Claude Desktop, Cursor, and anything else taking JSON

{
  "mcpServers": {
    "postgres-schema": {
      "command": "npx",
      "args": ["-y", "postgres-schema-mcp"],
      "env": {
        "DATABASE_URL": "postgres://mcp_reader:PASSWORD@localhost:5432/yourdb"
      }
    }
  }
}

As a desktop bundle

Clients that install a single file rather than run npx can use the .mcpb bundle from the releases page. It carries its own dependencies, so there is no install step, and it prompts for the connection string rather than having it pasted into a config file. Build one yourself with npm run bundle.

Set up the role first

Do not point this at a superuser. Create a role that can only read, and let the database enforce what the server also enforces:

CREATE ROLE mcp_reader LOGIN PASSWORD 'a long random password';

GRANT CONNECT ON DATABASE yourdb TO mcp_reader;
GRANT USAGE ON SCHEMA public TO mcp_reader;
GRANT SELECT ON ALL TABLES IN SCHEMA public TO mcp_reader;

-- So tables created later are readable too, without another grant.
ALTER DEFAULT PRIVILEGES IN SCHEMA public GRANT SELECT ON TABLES TO mcp_reader;

Grant nothing else. No INSERT, no USAGE on sequences, no EXECUTE on functions you have not read. If a column holds something the agent should never see, do not grant SELECT on the table and expose a view instead: the redaction described below matches column names, which is a convenience, not a boundary.

The tools

Tool	What it does
list_schemas	Schemas with a count of what each holds. Start here.
list_tables	Tables and views in one schema, largest first, with estimated rows and on-disk size
describe_table	Columns, types, nullability, defaults, keys, indexes, constraints and comments
find_columns	Search column names, and optionally types, across every schema
table_relationships	Follow foreign keys in both directions, N hops deep
sample_rows	The first N rows of a table, redacted and capped
run_select	One read-only query, with the guard, the timeout and the caps
explain_query	The plan for a query. ANALYZE is off by default and opt-in
export_data_dictionary	Write a Markdown data dictionary to a file

find_columns is the one that matters in a large database. Nobody browses a thousand tables, but everybody knows they are looking for something called customer_id.

export_data_dictionary is the one that changes how the server is used. Once the file exists, an agent working on that codebase can read the schema from disk with no connection and no credentials, which is the common case for someone writing a migration on a laptop that cannot reach production. It is also the only tool here that writes anything anywhere, and it only writes to the path you give it, which must end in .md.

Configuration

Variable	Default	What it does
DATABASE_URL	required	Connection string. Point it at the read-only role.
PGSM_MAX_ROWS	200	Row cap on every result
PGSM_MAX_BYTES	100000	Size cap on every result, which is the one that protects the agent's context
PGSM_STATEMENT_TIMEOUT_MS	10000	Per-statement timeout
PGSM_IDLE_TX_TIMEOUT_MS	15000	Idle-in-transaction timeout
PGSM_MAX_POOL	4	Connection pool size
PGSM_ALLOWED_SCHEMAS	all	Comma-separated allowlist. Everything else becomes invisible.
PGSM_REDACT_PATTERN	see below	Regular expression matched against column names

Both caps report when they bite. A truncated result says so in words, because an agent that silently receives half a result will reason confidently about the wrong answer.

Redaction

Columns whose name matches PGSM_REDACT_PATTERN come back as [redacted] from sample_rows and run_select alike. The default covers password, secret, token, ssn, credit_card, api_key, private_key and similar.

Be clear about what this is: it matches the name, not the value, so it will not notice a password stored in a column called notes. It is a guard against the ordinary mistake, not a classifier. The boundary is the GRANT.

HTTP mode, for a team

PGSM_TOKENS_FILE=./tokens.json PGSM_HTTP_PORT=3000 npx postgres-schema-mcp-http

Every request needs Authorization: Bearer <token>. There is no unauthenticated HTTP mode, and the server will not start without at least one token.

[
  {
    "name": "analytics",
    "token": "generate with: openssl rand -hex 32",
    "schemas": ["public", "reporting"],
    "tools": ["list_schemas", "list_tables", "describe_table", "find_columns", "run_select"]
  }
]

schemas and tools are both optional; omitting one means "everything the server exposes". A token can only ever be more restricted than the server it talks to, never less.

Scope is enforced by absence. A tool outside a token's scope is never registered on that session, so it does not appear in tools/list and calling it returns "unknown tool" rather than "forbidden". A refusal that says "forbidden" confirms the tool exists, and a token holder should not be able to map the rest of the server by reading the shape of its refusals. Every authentication failure returns the same 401 body for the same reason.

Tokens are compared by SHA-256 digest in constant time, and every configured token is checked even after one matches, so response time does not depend on a token's position in the list.

Put TLS and a reverse proxy in front of this. It binds to 127.0.0.1 unless you set PGSM_HTTP_HOST, and that default is deliberate.

Try it without a database of your own

docker compose -f examples/demo/docker-compose.yml up -d

DATABASE_URL='postgres://mcp_reader:demo_password_not_for_production@localhost:55432/bookshop' \
  npx postgres-schema-mcp

That starts PostgreSQL with a small bookshop schema: five tables, a view, a four-level foreign key chain, comments, and a password_hash column so redaction is visible in real output. It is written for this repository, so there is no licence question about redistributing it. The container keeps its data in tmpfs and forgets everything when it stops.

Pagila and Chinook both work fine too if you want something larger.

A question worth asking it, because no single tool answers it:

Which tables reference the customers table, and what is the average order total per customer?

The agent has to chain find_columns, table_relationships and run_select to get there.

Development

npm install
docker compose -f examples/demo/docker-compose.yml up -d
npm run build      # the protocol tests spawn dist/index.js, so build first
npm test
npm run bundle     # optional: builds the .mcpb into bundle/

182 tests. The integration suites skip themselves when no database is reachable, so npm test works on a laptop without Docker; CI asserts they did not skip, because a silent skip there would look exactly like a pass.

File	What it covers
test/injection.test.ts	Thirty hostile statements, each refused, grouped by technique
test/guard.test.ts	The queries that must be allowed, several containing the words the guard looks for
test/safety.test.ts	Redaction and the row and byte caps
test/tokens.test.ts	Token parsing, scope, and the write-mode switch that does not exist
test/cli.test.ts	--help and --version on both binaries, run with a deliberately empty environment
test/protocol.test.ts	A real MCP handshake over stdio against a real PostgreSQL, every tool
test/auth.test.ts	HTTP transport: valid, missing, wrong and out-of-scope tokens

guard.test.ts is there because a filter that refuses everything passes all thirty hostile cases and is useless. It asserts that SELECT 'drop table users', a column named updated_at, and a LIKE pattern containing ; DROP TABLE all still work.

Licence

MIT. See LICENSE.
