ESP32 Wake-on-LAN Telegram Bot

An ESP32-based Telegram bot that can remotely power on your PC using Wake-on-LAN (WOL) magic packets. This project turns a low-power ESP32 dev board into a dedicated device for waking your PC from anywhere, controlled securely through your personal Telegram account.

🚀 Features

• Wake your PC from anywhere with /wol command
• Controlled securely via Telegram Bot Token + User ID
• Lightweight, low-power solution (ESP32 uses <0.5W)
• Automatic reboot every 4 hours to prevent freezes
• Works without Raspberry Pi, static IP, or local servers

---

🛠️ Setup Process

1. Hardware & Drivers

• Board: ESP32-WROOM-32 Dev Kit (SquadPixel, DOIT DevKit V1, etc.)
• Install Arduino IDE
• Add ESP32 board package (https://dl.espressif.com/dl/package_esp32_index.json) in File → Preferences
• Install CP210x USB-to-UART Bridge drivers
• In Arduino IDE, select Board → ESP32 Arduino → DOIT ESP32 DEVKIT V1

Here’s how the Arduino IDE looks once configured:

---

2. Create a Telegram Bot

1. In Telegram, search @BotFather → /newbot
2. Copy the Bot Token it provides
3. Get your Telegram User ID via @userinfobot
4. Save both — they’ll be added into the code

---

3. Configure Arduino Code

Install required libraries in Arduino IDE:

• WakeOnLan
• UniversalTelegramBot
• ArduinoJson

Update the .ino file with your credentials (use placeholders before pushing to GitHub):

#define BOT_TOKEN  "your_bot_token_here"
#define ALLOWED_ID "your_user_id_here"

#define WIFI_SSID  "your_wifi_ssid"
#define WIFI_PASS  "your_wifi_password"

#define MAC_ADDR   "XX:XX:XX:XX:XX:XX"   // target PC MAC address

---

4. Flash and Run

• Connect ESP32 via USB and select correct COM port in Arduino IDE
• Upload the sketch
• Open Serial Monitor to confirm WiFi + Telegram connection

Here’s the ESP32 board used in this project:

---

📱 Usage

Once powered, the ESP32 automatically connects to WiFi + Telegram and listens for commands.

• /start → shows available commands
• /wol → sends the magic packet, waking up your PC

Example bot interaction:

---

🎥 Live Demo

Here’s a live demo of the project in action:

---

📚 References

This project was inspired and adapted from:

• coppermilk/esp32_wol_telegrambot (GitHub repo)
• ESP32 WakeOnLan: Remote Computer Start – by Artem Ger (Medium)
• How to set up ESP32-WROOM-32 – by Samuel Adesola (Medium)
• Setting up an ESP-WROOM-32 – by Jethro Muller
